Handheld Capnography Monitor

  • Lightweight and portable, work independently;

  • Lower power consumption, longer working time;

  • Using imported electronic components, it has the advantages of accurate numerical value and stable waveform.

Get Price
Specification Details

Specification of Handheld Capnography Monitor

ProjectParameter Description
RangeEtCO2& FiCO2：0-99 mmHg,0-9.9 kPa,0-10%
SpO2：0-100%
TEMP：25 to 45C
RR：3-99 rpm
PR：20-300 bpm
AccuracyEtCO2 & FiCO2：0-40 mmHg ±2 mmHg; 41-99 mmHg ±6% of reading
0-5.3 kPa ±0.3 kPa: 5.4-9.9 kPa ±6% of reading
SpO2：±2%(70-100%)
TEMP：±0.2C
RR：±1rpm
PR：±1bpm
Operating ENVIRONMENTAL0 to 40 C,10-95% RH,(non-condensing), 70-120 kPa
Storage ENVIRONMENTAL-20 to 70 C,10-95% RH,(non-condensing),50-120 kPa
DISPLAYColour LED,262kk colours, 3.5inch,320(RGB)x480
Power TypePower Supply or Built-in lithium battery (3500mAh）
Battery Life6 hours (Full load: EtCO2 & SpO2 & TEMP)
Power Supply90-260VAC/5VDC,50-60Hz
Dimensions5.9 x 2.7 x 1.1 in (148x68x27 mm)
Weight9.5 oz (270 g) (Built-in lithium battery)


Details of Handheld Capnography Monitor

Quick Details of Handheld Capnography Monitor

Real-time monitoring of the patient’s EtCO2 waveform, EtCO2 value, respiratory rate (RR), SpO2 value, pulse rate (PR), and body temperature. Real-time monitoring data is recorded and exported as a basis for diagnosis. We offer a variety of configurations, along with related accessories and consumables, to suit different needs.
